OT 20/170-240/800 4DIMLT2 G2 CE

EAN: 4052899981928
33,97 € (+ 20% VAT)

You need to register / log in to buy
Sales unit
  • 1 pcs
Product family features
  • Input voltage: 220…240 V
  • Current output range: 70…1,050 mA
  • Easy and fast wireless luminaire programming via NFC
  • Flexible current setting with one additional wire (LEDset2)
  • AstroDIM for autonomous dimming with five independent levels (astro, time mode)
  • Allows for energy saving in twilight phases
  • MainsDIM function for dimming via reduction of line voltage amplitude
  • Isolated DALI interface for bidirectional telemanagement systems
  • Standby power consumption: < 0.5 W
  • Constant Lumen Output (CLO)
  • Overtemperature protection via external NTC
  • Integrated customizable thermal management (Driver Guard)
Product family benefits
  • 4DIM functionality in one device (StepDIM, AstroDIM, MainsDIM, DALI)
  • Easy and fast wireless luminaire programming
  • Very high efficiency
  • Wide current output range: 200 mA…1050 mA
  • High surge protection: up to 10 kV (in protection class I or II)
  • Great flexibility due to wide operating temperature range of -40…55 °C or 60 °C
  • Protection through double isolation between mains input and LED output
Areas of application
  • Street and urban lighting
  • Industry
  • Suitable for outdoor applications in luminaires with IP > 54
  • Suitable for use in outdoor luminaires of protection class I and II
Family data sheet View downloads

Products

Product Nominal output current Nominal output voltage Data sheet
OT 75/170-240/1A0 4DIMLT2 G2 CE 200…1050 mA 35…115 V
OT 40/170-240/1A0 4DIMLT2 G2 CE 200…1050 mA 15…56 V
OT 165/170-240/1A0 4DIMLT2 E 200…1050 mA 130…260 V
OT 110/170-240/800 4DIMLT2 G2 CE 200…1050 mA 80…220 V

Downloads

Data sheets, brochures and technical information
