OT 110/120-277/1A4 2DIMLT2 P

EAN: 4052899253438
44,05 € (+ 20% VAT)

You need to register / log in to buy
Sales unit
  • 1 pcs
Product family features
  • Available with different wattage: 50 W, 100 W, 110 W
  • Input voltage: 120…277 V
  • Available with output current range: up to 1,400 mA
  • Flexible current setting with one additional wire (LEDset2)
  • AstroDIM for autonomous dimming with five independent levels (astro mode)
  • Isolated 0…10 V interface for unidirectional telemanagement systems
  • Constant Lumen Output (CLO)
  • Overtemperature protection with external NTC or LEDset2 interface
Product family benefits
  • 2DIM functionality in one device (AstroDIM, 0…10 V)
  • High surge protection: up to 6 kV (in protection class I or II)
  • Fast programming without mains voltage
  • High efficiency
  • Great flexibility due to wide operating temperature range of -40…55 °C
  • Protection through double isolation between mains input and LED output
  • IP rating: IP64
Areas of application
  • Street and urban lighting
  • Industry
  • Suitable for use in outdoor luminaires of protection class I and II
Equipment / Accessories
  • OT Programmer hardware for configuration of 2DIM ECGs necessary
  • Programmable via Tuner4TRONIC software
Family data sheet View downloads

Products

Product Nominal output voltage Nominal output current Data sheet
OT 50/120-277/800 2DIMLT2 P 30…115 V 350…800 mA
OT 50/120-277/1A2 2DIMLT2 P 20…55 V 600…1250 mA
