DALI ECO CONTROL
EAN 6937186166876
Product family features
- 2 channel light control with DALI interface
- Daylight-dependent regulation and presence-dependent control of light
- 100 hours burn-in function for fluorescent lamps
- Operation via standard pushbutton or IR remote control
- Outputs with adjustable offset
- Outputs with electronical reversible overtemperature, short-circuit, overload protection
- Connection of up to 4 DALIeco LS/PD LI or 6 DALI LS/PD LI sensors
- Connection of up to 4 light and presence sensors via 4p4c plug system
- Individual adjustment of functional parameters via IR remote control
- Halogen free polycarbonate plastic housing
- Sensor connection via polarity reversal protected 4p4c socket (RJ10)
- Simplified startup thanks to predefined operation modes
- Automatic and manual setting of regulation set point
- Offices
- Classrooms
- Training rooms
- Corridors
- Ceiling or independent installation via ECO CI KIT possible
- Suitable for up to 32 electronic control gears
Downloads
CED_I-E20 61347-2-11 devices · Certificates · 0B
⭳ download
DALI REP LI SO CE 3560605 06 040325 · Mandatory Publications · 0B
⭳ download
DALI ECO Control | 3-dim STEP · CAD data 3-dim · 0B
⭳ download
DALI ECO 3PDF 030326 · CAD data 3-dim · 0B
⭳ download
G15131575 DALI ECO CONTROL UI 210126 · User instruction · 0B
⭳ download
